IMAGE PLANT, PALAKKAD

The plant is situated in the midst of 25 acres of land. There are 5 main buildings & few small buildings for the plant with a total plinth area more than 97958.22 sq.ft

Buildings

1. ) Incinerator Plant Buildings (Plant I, II & III)
2. ) Autoclave Plant Building
3. ) Discarded Medicine Shed
4. ) Processed Red Waste Sorting Plant
5. ) Processed Scrap Storage Shed
6. ) Ash Storage Shed
7. ) Effluent Treatment Building
8. ) Sewage treatment Plant
9. ) Bottle Processing Unit
10. ) Canteen
11. ) Office Buildings
12. ) Conference Hall
13. ) Security and Office
14. ) Staff Rest Area
15. ) Vehicles washing area
16. ) Cloak Room

Installed Equipment & Capacity in IMAGE Plant

Total Incinerable Capacity of is 2000 Kg/Hr. The plant is working 24 hours per day. The daily incinerable capacity of the incinerators is 48 tones per day.

Autoclaves

High Pressure Sterilizer 5 Nos. Out of which, 2 of them are 1000 Ltrs Capacity (approx. 100kgs) each and 3 of them is 3000 Ltrs capacity (approx. 300 kgs) per cycle. We can operate 24 cycles per day in these autoclaves. The total daily autoclavable capacity is 26 tonnes per day.

Effluent Treatment Plant (ETP)

4.5 Lakhs Litres per day

Other Essential Utilities & Equipment in the plant are

1. ) Fuel storage tank
2. ) Bore wells and Pump
3. ) Effluent Treatment Plant
4. ) Sewage Treatment Plant
5. ) 380 KVA Generator
6. ) 400 KVA Generator (Standby Generator)
7. ) Ash storage and handling area
8. ) Weighing Machines
9. ) Transformers
10. ) Chimneys of 30 Mtr height
11. ) Hydraulic bundling machines
12. ) Scrap grinders
13. ) Bottle sorting machines
14. ) Conveyor belt system
15. ) Rain water harvest
16. ) CCTV Camera with Recorders
